Grills Diffuser

Aerofoil louvers with 0, 150, 300, and 450 deflection suitable for side wall, floors sill and ceiling mountings.

Types

Single deflection
Double deflection

Materials

Extruded Al, mild steel or stainless steel.

Finish

Powder coated, anodized, emulsion painted, primer coated,

Technical Specification

Designed with Nylon Bushes for efficient, smooth and quiet operation & to avoid rattling noise.
Aerofoil shaped blades
Deflection blades are adjustable manually and individually
Standard 20mm blade spacing
Single / Double deflection with high Quality anodizing or powder coating
With or Without Opposed blade Dampers
Available in different Standard sizes
Non standard sizes also manufactured upon request
Manufactured in High Quality aluminum extrusion profiles

Square

Free four way distubution pattern

Rectangular

Free four way distribution system

Circular

360 draft free air distubution patterns

Technical Specification

Designed to reduce ceiling smudging. Brings about proper airflow pattern and uniform air distribution.
Manufactured from aluminum sheets in one piece. (No joints / gaps at corners)
Negligible resistance to air flow.
Available as 4-Way Supply and Return Diffuser. (With or Without Opposed Blade Damper)
Less dirt accumulation.
Powder coated in attractive colors.
Material of construction: Aluminum /mild steel / stainless steel
